Frame:
Aluminium E - MTB frame designed to take a 720wh battery and Shimano STEPs EP8, E8000 or E7000 motor. Battery integrated inside frame.The geometry is designed for trail riding. This frame has tyre clearance for 29 x 2.6" tyres.
Headset:
Token TK035A-15 Sealed Bearing
Frame Axle Spacing:
148x12mm, P.1.75
Front Axle Specification:
110x15 mm
Hanger Type:
Hanger 03
Motor:
Shimano E7000 Motor
Battery:
Darfon 720Wh, 36V, 20Ah Li-Ion Battery, 3.8Kg Weight
Charger:
Darfon 720Wh, 36V, 20Ah Li-Ion Battery, 3.8Kg Weight
Display:
Shimano SW-E7000, Left
Switch:
Shimano SW-EM7000, Left
Fork:
RockShox Recon Silver 130mm
Fork Travel:
140mm
Crankset:
Shimano FC-EM600
Shifters:
R: Shimano SL-M5100-R Deore, 11 Speed Rapidfire Plus
Rear Derailleur:
Shimano RD-M5100 Deore, 11 Speed
Cassette:
Shimano CS-M5100 Deore, 11 Speed 11-51T
Chain:
KMC X11-1 11 Speed
Brakes:
F: Shimano MT410, Resin Pads
R: Shimano MT410, Resin Pads
Rotors:
F: Shimano SM-RT10 180mm, 6-Bolt
R: Shimano SM-RT10 180mm, 6-Bolt
Grips:
SBC Lockon Grip
Handlebar:
SURFACE alloy Trail 35mm Handlebar, Backsweep 6°, Rise 12mm
Stem:
SURFACE Trail alloy Stem
Saddle:
Surface E-Bike Ergo
Seat Post:
SURFACE Dropper, 30.9mm
Seatpost Clamp:
SURFACE Alloy
Wheelset:
SUNringlé Custom
Hubs:
F: Surface 15x110mm, 6 Bolt
R: Surface, 148x12mm, 6-Bolt
Rims:
F: SUNringlé Duroc 35, STR Tubeless ready, 32mm Internal Width
R: SUNringlé Duroc 35, STR Tubeless ready, 32mm Internal Width
Tyres:
F: Maxxis Assegai, 29x2.50WT, EXO+ TR, 3C MaxxTerra
R: Maxxis Assegai, 29x2.50WT, EXO+ TR, 3C MaxxTerra
Weight:
21.5kg
