Frame
New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, 6061 Alloy, full length internal routing, replaceable derailleur hanger, integrated mount for 40mm direct-mount 2-bolt kickstand
Headset
Semi-Integrated, ZS44/28.6 ZS56/40
Frame Axle Spacing
135x9mm
Axle Specification
QR
Hanger Type
Hanger 22
Fork
SR Suntour XCR32-ATB Air, 100mm Travel, 32mm Black Stanchions, 29"
Wheelset
Surface Custom
Hubs
F: Shimano, 100x9mm QR, 6 Bolt, 32H
R: Shimano, 135x9mm QR, 6 Bolt, 32H
Rims
F: SURFACE 29" Symmetrical Alloy Rim, Tubeless Ready
R: SURFACE 29" Symmetrical Alloy Rim, Tubeless Ready
Tyres
F: CST 1820 29x2.35;
R: CST 1820 29x2.35
Max Tyre Size
2.4"
Crankset
Shimano Cues U4000-1, 32T
Max Chainring Size
36T
Bottom Bracket & Type
BSA 73
Shifter(s)
L: NIL
R: Shimano Cues SL-U4000-9R, Rapidfire Plus, 9-Speed
Front Derailleur
N/A
Rear Derailleur
Shimano Cues RD-U4000, 9-Speed
Cassette
Shimano Cues CS-LG400-9, 11-46T, 9-Speed
Chain
Shimano CN-LG500 Linkglide
Brakes
Tektro MD-M275 Hydraulic Disc
Rotors
F: Tektro, 6-bolt, 180mm
R: Tektro, 6-bolt, 160mm
Grips
Surface Push-on
Handlebar
Alloy, Oversize. 9° backsweep, 12mm rise, 680mm width
Stem
Alloy 31.8mm Oversize, 6° rise
Saddle
Surface, Steel Rails
Seat Post
Alloy, 30.9mm
Seatpost Clamp
Surface QR, Alloy
Pedals
One piece alloy
Bike Weight
14.5kg (Including pedals 370g)
Rider Weight Limit
120kg - combined weight of bike and rider (including all kit).
